The MBR-610 motorised bead roller is much easier to use compared to manual machines to having your panels beaded in your home workshop or garage. Made from heavy plate steel and a massive 610mm throat depth making it perfect for strengthening any type of car roof, body panels, seals & guards etc.
This bead roller is electrically gear driven via a forward & reverse foot control switch that drives both the bottom and top bead rolls. The drive shafts are supported in quality bronze bearing bushes and incorporate with thrust ball bearings for additional support & accuracy.
The MBR-610 also includes a stand that also stores the twelve sets of the most common rolls required by any metal forming automotive enthusiasts or professional.
1.2mm mild steel capacity with 610mm throat
Variable speed dial for superior control on all applications
Forward / reverse foot pedal switches with emergency stop
Ø70mm hardened & keyed rollers for positive drive
105mm gap height between roller support arms
Allows clearance of up to 80mm on 90º return bends
Heavy duty steel plate construction for increased rigidity
Top & bottom roller shafts are geared & electrically driven
Adjustable top roller with 38mm of vertical travel
Top shaft adjusts horizontally to easily & accurately align dies
Ø25mm drive shafts with grease-able bronze bushes, Ø20mm spigot for mounting rollers
Adjustable material depth guide
0.25kW / 0.33hp, 240V variable speed motor with reduction gearbox
Fitted with two rear wheels to allow easy mobility
Includes a comprehensive range of rolls supplied as standard
