POWER HAMMER – PHM-560

Features

• Capacity – 1.6mm mild steel
• Strokes per minute = 0 – 960
• Throat height capacity – 395mm
• Throat depth capacity – 560mm
• Variable speed via inverter control
• Foot pedal control with emergency stop
• Steel fabricated upper frame – 12mm thick plate
• Steel fabricated lower box section steel frame
• Drive shafts have bronze bushes & greasing points
• Adjustable heavy duty single arm length stop with 1 round roller & guide fence
• Safety magnetic power switch
• Steel dies made from CR12 steel & hardened
• Nylon dies made from durable nylon
• 0.75kW / 1hp, 240V motor

Includes

 STEEL DIES

• • 1 set (pair) – universal holders with 16mm opening
  • 1 set (pair) – thumbnail shrinking dies
  • 1 set (pair) – doming dies
  • 1 x linear stretching die
  • 1 set (pair) – louvre dies

• • 1 set (pair) – 1/4″ beading dies
  • 1 set (pair) – 3/8″ beading dies
  • 1 set (pair) -1/2″ beading dies
  • 1 x steel upper die

• • 1 x steel lower die – 3/4″ radius
  • 1 x steel lower die – 7/8″ radius
  • 1 x steel lower die – 1″ radius die
  • 1 x steel lower die – 1-1/8″ radius
  • 1 x steel lower die – 1-1/2″ radius
  • 1 x steel lower die – 1-7/8″ radius
  • 1 x steel lower die – 2″ radius
  • 1 x steel lower die – 3″ radius
  • 1 x steel lower die – 4″ radius
  • 1 x steel lower die – 5″ radius
  • 1 x steel lower die – 6″ radius (1/16″ radius edge)
  • 1 x steel lower die – 6″ radius (1/4″ radius edge)
  • 1 x steel lower die – 8″ radius
  • 1 x steel lower die – 14-1/2″ radius
  • 1 x steel lower die – 24″ radius
  • 1 x steel lower die – 36″ radius
  • NYLON DIES

• • 1 x nylon upper die
  • 1 x nylon lower die – 3/4″ radius
  • 1 x nylon lower die – 7/8″ radius
  • 1 x nylon lower die – 1-1/8″ radius
  • 1 x nylon lower die – 1-1/2″ radius
  • 1 x nylon lower die – 1-7/8″ radius
  • 1 x nylon lower die – 4″ radius
  • 1 x nylon lower die – 5″ radius
  • 1 x nylon lower die – 6″ radius (1/16″ radius edge)
  • 1 x nylon lower die – 6″ radius (1/4″ radius edge)
  • 1 x nylon lower die – 8″ radius
  • 1 x nylon lower die – 14-1/2″ radius
  • 1 x nylon lower die – 24″ radius
  • 1 x nylon lower die – 36″ radius
